Angular Contact Ball Bearing For Magneto Application D 4-20mm

WELCOME TO DEMY BEARING，WELCOME TO VISIT OUR FACTORY

FOB Price:

Min.Order Quantity: 500-1000 Pieces

Supply Ability: 100000 Pieces/per Month

Port: Ningbo/Shanghai

Payment Terms: T/T,L/C

Product Detail

Boundary dimensions (mm)					Basic load rating (KN)		Limiting speed (r/min)		Bearing Numbers		Abutment and fillet dimensions(mm)			Weight (reference) (kg)
d	D	B	r1,2 min	r3,4 min	Cr	Cor	Grease	Oil	Series E	Series EN	da min	Da max	ra max	Weight (reference) (kg)
4	16	5	0.15	0.10	1.65	0.288	34000	40000	E4	EN4	5.2	14.8	0.15	0.005
5	16	5	0.15	0.10	1.65	0.288	34000	40000	E5	EN5	6.2	14.8	0.15	0.004
6	21	7	0.30	0.15	2.49	0.445	30000	36000	E6	EN6	8.0	19.0	0.30	0.011
7	22	7	0.30	0.15	2.49	0.445	30000	36000	E7	EN7	9.0	20.0	0.30	0.013
8	24	7	0.30	0.15	3.45	0.650	28000	34000	E8	EN8	10.0	22.0	0.30	0.014
9	28	8	0.30	0.15	4.55	0.880	24000	30000	E9	EN9	11.0	26.0	0.30	0.022
10	28	8	0.30	0.15	4.55	0.880	24000	30000	E10	EN10	12.0	26.0	0.30	0.021
11	32	7	0.30	0.15	4.40	0.845	22000	26000	Ell	EN11	13.0	30.0	0.30	0.029
12	32	7	0.30	0.15	4.40	0.845	22000	26000	E12	EN12	14.0	30.0	0.30	0.028
13	30	7	0.30	0.15	4.40	0.845	22000	26000	E13	EN13	15.0	28.0	0.30	0.021
14	35	8	0.30	0.15	5.80	1.150	19000	22000	–	EN14	16.0	33.0	0.30	0.035
15	35	8	0.30	0.15	5.80	1.150	17000	22000	E15	EN15	17.0	33.0	0.30	0.034
16	38	10	0.60	0.20	6.90	1.380	17000	22000	–	EN16	20.0	34.0	0.40	0.049
17	44	11	0.60	0.30	7.35	1.500	16000	19000	–	EN17	21.0	40.0	0.60	0.080
18	40	9	0.60	0.20	5.05	1.030	17000	20000	–	EN18	22.0	36.0	0.40	0.051
19	40	9	0.60	0.20	5.05	1.030	16000	19000	E19	EN19	23.0	36.0	0.40	0.049
20	47	12	1.00	0.60	11.00	2.380	16000	19000	E20	EN20	25.0	42.0	1.00	0.089
